Rig Breakdown

LED walls used to be this big scary new tech. In the early days things like hertz and frame rates would be either a mystery or a guessing game, lighting was a challenge, and camera tracking was a nightmare. The playbook had not yet been created. Just like with the advent of LED lighting, things take time to adjust and integrate into workflows. You realize what systems need improving, understand your base standards for execution, and figure out all the little quirks and tips that come with new technology.

We put the virtual production workflow to the test during our shoot for Cadillac.

With one combined prelight / tech rehearsal day, and two shoot days, this set of Cadillac TVCs featured 5 different vehicles in 6 different virtual environments.  All of the vehicle interiors for the spots were captured with ICVFX (in camera vfx) on Nant Studio’s LED Volume 1 in El Segundo. With the help of some extensive prep & previz, Brendan, Vince, and I were able to move at record pace for a commercial with intricate technical requirements.

Lots of fun on this 3 day commercial shoot with a couple of different locations for a well known popcorn brand. Our first location was at Air Hollywood. We shot both inside in an airplane buck and outside in the parking lot. For our first setup outside in the parking lot we built a Modulus-X 9” truss rig and secured it onto a 12054 telehandler to hang a hot air balloon basket. I wanted to get the pick point out a little further away from the carriage which is why we didn’t just pick it off the bottom hook of the carriage. We used Modulus-X 9” because I co-own Division and we have it readily available. When building a rig that sticks out further than the telehandler it’s generally good practice to integrate a vertical member into your rig. This distributes the force in the components (in this case a singular piece of truss) sticking out. We secured the vertical portion of the rig to the carriage as well with both a basketed 2” ratchet and SK clamps. The load rating of 9” ModX is insane, so it was never really a worry, but it’s good practice. A 6’ stick of the 9” boasts a roughly 15,000# uniform center load WLL just to give you an idea.

The hot air balloon company took care of attachment for the balloon to the telehandler - they have a special rig they use all the time with film productions.

It was overcast and drizzly but we set up so that if the sun did peak out it would be backlit. Popped a 20x20 chroma blue behind the basket for vfx as they were supposed to be way up in the sky. Whenever I’m worked with a 20x20 frame that doesn’t work tabled I like to put it on either black bird cranks or long johns. It makes it way more manageable to work with. We shaped in some negative fill with a 12x20 water solid and angled a 20x20 water solid swatter overhead. Gaffer Mathias Peralta key’d talent with an M90 thrown through some color and diffused through a 12x grid. He backlit with an 18k on a 60’ articulating boom and blasted through some color on that too.

After we got rained out we finished off a bit of the balloon basket inside still against blue screen and transitioned over to the airplane. We lit with more warm sun to match the hot air balloon look and injected some day blue ambience into the cockpit to simulate the clear sky.
